2016 professional two color ink cup golf ball pad printing machine from China Manufacturer

Type:PAD PRINTER
Place of Origin:CN;GUA
Gross Power:40W
Plate Type:GRAVURE
Brand Name:ENGY
Condition:New
Usage:Bill Printer
Usage:Card Printer
Usage:Cloths Printer
Usage:Label Printer
Usage:Paper Printer
Usage:Tube Printer
After-sales Service Provided:Overseas service center available
Voltage:110V / 220V
Certification:CE Certification
Color & Page:Two colors
Dimensions(L*W*H):L680 x W460 x H1310 mm
Automatic Grade:Semi-automatic
Weight:78kg
Model Number:EN-C125/2S
Description of product:2 Color Closed Cup Pad Printer
Printing color:2 color
Plate size:200x100 mm
Ink cup size (diameter):ID82*OD90mm
Plate thickness:0.5mm
Warranty:one year
Printing capacity:1800 cycles/hour
Drive:Pneumatic
Air consumption:91litre/min(5bar)
key words:golf ball pad printing machine

2016 professional two color ink cup golf ball pad printing machine

Product Description

2016 professional two color ink cup golf ball pad printing machine Standard Features

Standard Features:

*Suitable for 2 color small size printing, widely apply in many industries including stationery, toys, plastic, gift, electrical appliances, electronic, etc;
*Microprocessor operation system, electro-pneumatic control;
*125mm standard stroke, ink cup design, no smell and low evaporation;
*Independent adjustment of up and down, forward and rear stroke;
*Versatile X, Y printing pad adjustment;
*Ink cup base with X, Y, Z adjustment;
*The shuttle is disassembly flexible;
*Heavy-duty construction with cabinet ensures years of reliable operation;
*Stable, durable working and fine workmanship;
*Foot pedal operation for single cycle;
*Using Germany FESTO pneumatic components;
*Installed safety guard and emergency stop button(optional);
*Complying with CE safety standards.

2016 professional two color ink cup golf ball pad printing machine Specifications:

Model NO.	EN-C125/2S
Plate size	200 x 100mm
Max. printing size	80x80mm
Printing capacity	1800 cycles/hour
Drive	Pneumatic
Front & back working stroke	125mm
Air requirement	5 bar (72.5 psi)
Main voltage	110V/220V 50/60Hz 40W
Machine size	L680 x W460 x H1310 mm
Weight	78kg

2016 professional two color ink cup golf ball pad printing machine Details:

Applications

Fields of Pad Printer Application:
Pad printer is widely applied in many industries including toys, plastic, electronic, glass, metal, electrical appliances, ceramics, die-casting products, optical, sporting goods, stationery, etc.
For example, rulers, pens, golf balls, ping-pong, eyes of doll, cap of bottle, watches, cameras, ceramic, pharmaceutical and medical equipment, rackets, tapes, electronic components, IC, CPU, DRAM, keyboard, mouse, cell phone shell, decorative signs, etc.
